Product Information

Charger model:

UY1200

Power:

1200W

Shell material:

Aluminum Alloy (Color: Silver/Black/Customizable)

Size:

260*150*90mm

Input:

90-130Vac/200-260Vac 47~63Hz

Operating temperature:

-20 to 40

Heat dissipation:

Fan intelligent temperature control speed regulation, quiet noise is small

Protection:

Over temperature protection, charging over/over current protection, short circuit protection, reverse connection protection

Features:

The charger MCU control, optional communication RS485/CANBUS/Bluetooth Bluetooth function, support battery over-discharge activation charging, can be 0V charging.

Model

Specifications

Output voltage

Reference

Maximum charging current

Full turn light

Setup

Li-ion

ternary lithium

LiFePo4

lithium iron phosphate

Lead-acid

lead acid

Lithium battery

lead acid

UY1200

12V50A

12.6V/16.8V

14.6V

14.7V

50A

8%

25%

24V35A

25.2V/29.4V/33.6V

29.2V

29.4V

35A

8%

25%

36V25A

42V

43.8V

44.1V

25A

8%

25%

48V20A

50.4V/54.6V/58.8V

58.4V

58.8V

20A

8%

25%

60V15A

67.2V/71.4V

87.6V

73.5V

15A

8%

25%

72V12A

84V/88.2V

87.6V

88.2V

12A

8%

25%

84V10A

96.6V/100.8V

102.2V

102.9V

10A

8%

25%

Note: The above parameters are for reference only. Our company can customize various parameters such as voltage and current as required!
